MSCSM120AM31CTBL1NG Original stock-wholesale price

The image is for reference only



MSCSM120AM31CTBL1NG

Manufacturer Model： MSCSM120AM31CTBL1NG
Manufacturer： Microchip Technology
Package/Specification

Product Description： PM-MOSFET-SIC-SBD-BL1

Place of delivery：China （Including VAT） Lead time(weekday）：2 hour shipping

Stock：

Spot goods3590（1 Starting order） (China：2 hour shipping)

Quantity：x175.84000（unit-price）Not the latest price, please consult customer service for details「Package(TR) / 1」

Consult Now

Advantage spot

4-11404-2

T3477-018

SBM51214G

I-2X12FOM3LM-CAS-MA

I-2X12FOM3LM-CAS-MB

I-2X12FOM3LM-CAS-FA

Product Details
Technical Documentation

Product Classification	Transistors - FETs, MOSFETs - Arrays
Mfr	Microchip Technology
Series	-
Package	Bulk
Product Status	Active
FET Type	2 N Channel (Phase Leg)
FET Feature	Silicon Carbide (SiC)
Drain to Source Voltage (Vdss)	1200V
Current - Continuous Drain (Id) @ 25°C	79A
Rds On (Max) @ Id, Vgs	31mOhm @ 40A, 20V
Vgs(th) (Max) @ Id	2.8V @ 1mA
Input Capacitance (Ciss) (Max) @ Vds	232nC @ 20V
Input Capacitance (Ciss) (Max) @ Vds	3020pF @ 1000V

Technical Documentation
Data Book	MSCSM120AM31CTBL1NG.pdf
