PN2222ANLBU Original stock-wholesale price

The image is for reference only



Fairchild Semiconductor PN2222ANLBU

Manufacturer Model： PN2222ANLBU
Manufacturer： Fairchild Semiconductor
Package/Specification

Product Description： TRANS NPN 40V 1A TO92-3

Place of delivery：China （Including VAT） Lead time(weekday）：2 hour shipping

Stock：

Spot goods3590（1 Starting order） (China：2 hour shipping)

Quantity：x（unit-price）Not the latest price, please consult customer service for details「Package(TR) / 1」

Consult Now

Advantage spot

4-11404-2

T3477-018

SBM51214G

I-2X12FOM3LM-CAS-MA

I-2X12FOM3LM-CAS-MB

I-2X12FOM3LM-CAS-FA

Product Details
Technical Documentation

Product Classification	Transistors - Bipolar (BJT) - Single
Mfr	Fairchild Semiconductor
Series	-
Package	Bulk
Product Status	Obsolete
Transistor Type	NPN
Current - Collector (Ic) (Max)	1 A
Voltage - Collector Emitter Breakdown (Max)	40 V
Vce Saturation (Max) @ Ib, Ic	1V @ 50mA, 500mA
Current - Collector Cutoff (Max)	10nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	100 @ 150mA, 10V
Frequency - Transition	625 mW
Frequency - Transition	300MHz

Technical Documentation
Data Book	PN2222ANLBU.pdf
