2SD1760TLP Original stock-wholesale price

The image is for reference only



2SD1760TLP

Manufacturer Model： 2SD1760TLP
Manufacturer： Rohm Semiconductor
Package/Specification

Product Description： TRANS NPN 50V 3A CPT3

Place of delivery：China （Including VAT） Lead time(weekday）：2 hour shipping

Stock：

Spot goods3590（1 Starting order） (China：2 hour shipping)

Quantity：x0.34122（unit-price）Not the latest price, please consult customer service for details「Package(TR) / 1」

Consult Now

Advantage spot

4-11404-2

T3477-018

SBM51214G

I-2X12FOM3LM-CAS-MA

I-2X12FOM3LM-CAS-MB

I-2X12FOM3LM-CAS-FA

Product Details
Technical Documentation

Product Classification	Transistors - Bipolar (BJT) - Single
Mfr	Rohm Semiconductor
Series	-
Package	Tape & Reel (TR)
Product Status	Not For New Designs
Transistor Type	NPN
Current - Collector (Ic) (Max)	3 A
Voltage - Collector Emitter Breakdown (Max)	50 V
Vce Saturation (Max) @ Ib, Ic	1V @ 200mA, 2A
Current - Collector Cutoff (Max)	1µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	82 @ 500mA, 3V
Frequency - Transition	15 W
Frequency - Transition	90MHz

Technical Documentation
Data Book	2SD1760TLP.pdf
