2SD2389 Original stock-wholesale price

The image is for reference only



Sanken 2SD2389

Manufacturer Model： 2SD2389
Manufacturer： Sanken
Package/Specification

Product Description： TRANS NPN DARL 150V 8A TO3P

Place of delivery：China （Including VAT） Lead time(weekday）：2 hour shipping

Stock：

Spot goods3590（1 Starting order） (China：2 hour shipping)

Quantity：x3.78000（unit-price）Not the latest price, please consult customer service for details「Package(TR) / 1」

Consult Now

Advantage spot

4-11404-2

T3477-018

SBM51214G

I-2X12FOM3LM-CAS-MA

I-2X12FOM3LM-CAS-MB

I-2X12FOM3LM-CAS-FA

Product Details
Technical Documentation

Product Classification	Transistors - Bipolar (BJT) - Single
Mfr	Sanken
Series	-
Package	Bulk
Product Status	Obsolete
Transistor Type	NPN - Darlington
Current - Collector (Ic) (Max)	8 A
Voltage - Collector Emitter Breakdown (Max)	150 V
Vce Saturation (Max) @ Ib, Ic	2.5V @ 6mA, 6A
Current - Collector Cutoff (Max)	100µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	5000 @ 6A, 4V
Frequency - Transition	80 W
Frequency - Transition	80MHz

Technical Documentation
Data Book	2SD2389.pdf
