2SD1815S-TL-H Original stock-wholesale price

The image is for reference only



onsemi 2SD1815S-TL-H

Manufacturer Model： 2SD1815S-TL-H
Manufacturer： onsemi
Package/Specification

Product Description： TRANS NPN 100V 3A TP-FA

Place of delivery：China （Including VAT） Lead time(weekday）：2 hour shipping

Stock：

Spot goods3590（1 Starting order） (China：2 hour shipping)

Quantity：x（unit-price）Not the latest price, please consult customer service for details「Package(TR) / 1」

Consult Now

Advantage spot

4-11404-2

T3477-018

SBM51214G

I-2X12FOM3LM-CAS-MA

I-2X12FOM3LM-CAS-MB

I-2X12FOM3LM-CAS-FA

Product Details
Technical Documentation

Product Classification	Transistors - Bipolar (BJT) - Single
Mfr	onsemi
Series	-
Package	Tape & Reel (TR)
Product Status	Obsolete
Transistor Type	NPN
Current - Collector (Ic) (Max)	3 A
Voltage - Collector Emitter Breakdown (Max)	100 V
Vce Saturation (Max) @ Ib, Ic	400mV @ 150mA, 1.5A
Current - Collector Cutoff (Max)	1µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	140 @ 500mA, 5V
Frequency - Transition	1 W
Frequency - Transition	180MHz

Technical Documentation
Data Book	2SD1815S-TL-H.pdf
