2SD1805G-E Original stock-wholesale price

The image is for reference only



onsemi 2SD1805G-E

Manufacturer Model： 2SD1805G-E
Manufacturer： onsemi
Package/Specification

Product Description： TRANS NPN 20V 5A TP

Place of delivery：China （Including VAT） Lead time(weekday）：2 hour shipping

Stock：

Spot goods3590（1 Starting order） (China：2 hour shipping)

Quantity：x0.27000（unit-price）Not the latest price, please consult customer service for details「Package(TR) / 1」

Consult Now

Advantage spot

4-11404-2

T3477-018

SBM51214G

I-2X12FOM3LM-CAS-MA

I-2X12FOM3LM-CAS-MB

I-2X12FOM3LM-CAS-FA

Product Details
Technical Documentation

Product Classification	Transistors - Bipolar (BJT) - Single
Mfr	onsemi
Series	-
Package	Bulk
Product Status	Obsolete
Transistor Type	NPN
Current - Collector (Ic) (Max)	5 A
Voltage - Collector Emitter Breakdown (Max)	20 V
Vce Saturation (Max) @ Ib, Ic	500mV @ 60mA, 3A
Current - Collector Cutoff (Max)	100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	280 @ 500mA, 2V
Frequency - Transition	1 W
Frequency - Transition	120MHz

Technical Documentation
Data Book	2SD1805G-E.pdf
