TPC6503(TE85L,F,M) Original stock-wholesale price

Toshiba Semiconductor and Storage TPC6503(TE85L,F,M)

The image is for reference only



Toshiba Semiconductor and Storage TPC6503(TE85L,F,M)

Manufacturer Model： TPC6503(TE85L,F,M)
Manufacturer： Toshiba Semiconductor and Storage
Package/Specification

Product Description： TRANS NPN 30V 1.5A VS-6

Place of delivery：China （Including VAT） Lead time(weekday）：2 hour shipping

Stock：

Spot goods3590（1 Starting order） (China：2 hour shipping)

Quantity：x（unit-price）Not the latest price, please consult customer service for details「Package(TR) / 1」

Consult Now

Advantage spot

4-11404-2

T3477-018

SBM51214G

I-2X12FOM3LM-CAS-MA

I-2X12FOM3LM-CAS-MB

I-2X12FOM3LM-CAS-FA

Product Details
Technical Documentation

Product Classification	Transistors - Bipolar (BJT) - Single
Mfr	Toshiba Semiconductor and Storage
Series	U-MOSVII
Package	Tape & Reel (TR)
Product Status	Obsolete
Transistor Type	NPN
Current - Collector (Ic) (Max)	1.5 A
Voltage - Collector Emitter Breakdown (Max)	30 V
Vce Saturation (Max) @ Ib, Ic	120mV @ 10mA, 500mA
Current - Collector Cutoff (Max)	100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	400 @ 150mA, 2V
Frequency - Transition	1.6 W
Frequency - Transition	-

Technical Documentation
Data Book	TPC6503(TE85L,F,M).pdf
